Qi EPP 12V 24V 36V fast wireless charging wireless charger pcba circuit board module AC DC adapter

Product Description

We are Shenzhen huagon technology who has been engaged in wireless charging module production and design for 10 years, we have any size pcb and any power receiver and transmitter, 2W for small electronic devices to 300W for medium industrial equipment wireless energy receiving and transmitting we have mature products, if you have an idea, we can make it happen, so please tell me your needs, usage, or size and power information, we will give you a perfect solution

This product uses S7 main control IC, supports Type-C interface communication upgrade, supports PD, AFC, QC communication protocols, a complete work protection system, low cost, ultra-low operating temperature, ultra-high working efficiency, can pass all export certifications, QI certification, able to quickly and wirelessly charge Samsung, iPhone, Huawei, Xiaomi, LG, Google, ZTE, Sony, Nokia, Hammer, Gionee and many other mobile phone brands that meet the QI standard with built-in wireless charging W wireless fast charging, at the same time, it has perfect compatibility with 5W wireless charging mobile phones that meet the QI standard, and can support Qi standard receivers such as Ti, IDT, PANASONIC and so on.

Input voltage?	?	24V/12V/9V/5V	?	?
?communication protocol	?	PD, AFC, QC	?	?
Interface	?	Type-C	?	?
Power?	?	5W / 10W /15W fast charge	?	?
Support fast charge protocol?	?	D, QC2.0, QC3.0, AFC	?	?
Inductive charging distance	?	1 ¡« 10mm	?	?
BPP / EPP working frequency	?	105Khz ¡« 205Khz	?	?
Work efficiency??	?	85%	?	?
OTP over temperature protection	?	YES	?	?
OCP over current protection	?	YES	?	?
OVP over voltage protection	?	YES	?	?
?UVP under voltage protection	?	YES	?	?
Certification	?	KC¡¢FCC¡¢CE¡¢BSMI	?	?

Precautions

The wireless charger HG-TX 30V 6050 is an inductive charger that complies with the WPC1.2.4 15W standard, designed to charge Qi compatible devices. Stable performance and low standby power consumption. Voltage regulation at a constant frequency can ensure high charging stability and high efficiency, and support 5V-30V wide voltage input to meet different power supply requirementsHG-TX 30V 6050 has built-in protection circuits for overcurrent, overheating, short circuit, overvoltage and undervoltage, and foreign body detection to ensure safe and reliable operation of the equipment. It is easier to integrate into public transportation vehicles. The charger can operate in a wide power supply voltage range of 5-30V DC to meet different power supply requirements.

Automotive wireless charging modules protection logic design

Static FOD: After working normally after power-on, when entering standby mode and not working, the static FOD function works. At this time, place a metal object about 2MM directly above the coil, covering half of the coil, and the metal content reaches a certain level, At this time, the static FOD triggers and enters the error reporting state, and the indicator flashes immediately to indicate the error.Dynamic FOD: After normal operation after power-on, after entering the charging mode from the standby mode, the dynamic FOD function works. At this time, if there is a metal object between the transmitting coil and the receiving coil, it is converted according to the transmitting power of the transmitting board and the received feedback power If the loss of conversion efficiency is too large, it is judged to be affected by metal objects. At this time, dynamic FOD is triggered. This conversion process depends on the actual situation. Normally, the error state is entered in about 15 seconds, and the error state is entered in up to 1 minute. And the indicator flashes immediately to prompt an error.

PCBA Certifications

Q1. Can I have a sample order for wireless chargers?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than?

Q3. Do you have any MOQ limit for wireless charger order?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for wireless charger?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on wireless charger product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 12 months warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new charger with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution?
including re-call according to real situation.

One coil 15W TX
